UniScan-V VLT Measuring System

Inspection system that accurately measures the light transmittance of transparent/translucent materials and automatically detects anomalies

Key Features -Equipment that accurately measures the light transmittance of materials with light-transmitting properties such as films, glass, membranes, and coating layers to determine whether the product is more than uniform and quality
-Measurement of light transmittance of tinting film attached to vehicle windows or building windows

Key Features -Quick real-time measurement of transmittance with simple operation
-Evaluate the required performance of the film by measuring the transmittance of visible light using the light source-light receiving method
-Automatic alarms and fault records when deviations are below or above a certain standard
-Automatically save heatmaps/statistics reports of examination results
-Precisely measure the consistency of the film by sampling the transmittance while crossing the camera at right angles to the film direction

Product Specifications

Category	Specification	Note
Camera	5M Area Scan
Resolution	40 ㎛ / pixel
Light	Bottom LED Bar Light
PLC	Ethernet or DIO
Items	Light transmission
Speed	20 Sample / s
